Rigid Stranding
Machine

Rigid
Stranding
Machine

Partnering with Trusted Brands to Deliver Quality Through Innovation and Advanced Technology.

Main Features

Heavy-duty cages with batch loading system or top Loading Hoist system. Advanced pneumatic or manual tension control Customizable take-up units (Ø1000 – Ø5500 mm) Reinforced frame with seamless steel main shaft Precision-ground gears for durability & efficiency Integrated pre-formers for smooth wire crossing Compliant with international safety standards	Torque-controlled dual capstans PLC + HMI user-friendly interface Independent motorized drive for low noise High-strength cast iron gearbox Flexible cage configurations Advanced loading system for easy maintenance Long service life for demanding production

Rigid Frame Stranding Machine – Technical Parameters

Individual Motor Belt Type

The machine features an independent motor belt drive system, allowing each cage section precise speed control. This reduces vibration, noise, and improves energy efficiency. Maintenance is simplified, and a high-quality Gate brand belt is used for optimal performance.

Bobbin Size (mm)	Material	Max. Cage Speed (rpm)					Wire Diameter (mm)
Bobbin Size (mm)	Material	6B	12B	18B	24B	32B	Wire Diameter (mm)
Φ 500	Aluminium / Alloy	300	260	230	200	175	Φ 1.6 – 5.0
Φ 500	Copper	200	175	150	130	115	Φ 1.6 – 5.0
Φ 630	Aluminium / Alloy	240	210	180	160	140	Φ 1.6 – 5.0
Φ 630	Copper	160	140	125	110	95	Φ 1.6 – 5.0

Bobbin Size: Φ 500

Material	Aluminium / Alloy
6B	300
12B	260
18B	230
24B	200
32B	175
Wire Diameter	Φ 1.6 – 5.0

Material	Copper
6B	200
12B	175
18B	150
24B	130
32B	115
Wire Diameter	Φ 1.6 – 5.0

Bobbin Size: Φ 630

Material	Aluminium / Alloy
6B	240
12B	210
18B	180
24B	160
32B	140
Wire Diameter	Φ 1.6 – 5.0

Material	Copper
6B	160
12B	140
18B	125
24B	110
32B	95
Wire Diameter	Φ 1.6 – 5.0

Individual Motor Direct Gearbox Type

Each cage section has its own motor and gearbox, ensuring no belt slippage, better torque, and precise synchronization. With fewer moving parts, maintenance is lower, reliability is higher, and the system is built for continuous heavy-duty operation.

Bobbin Size (mm)	Material	Max. Cage Speed (rpm)					Wire Diameter (mm)
Bobbin Size (mm)	Material	6B	12B	18B	24B	32B	Wire Diameter (mm)
Φ 500	Aluminium / Alloy	335	310	275	240	210	Φ 1.6 – 5.0
Φ 500	Copper	240	210	180	155	135	Φ 1.6 – 5.0
Φ 630	Aluminium / Alloy	290	250	210	190	170	Φ 1.6 – 5.0
Φ 630	Copper	190	170	150	130	115	Φ 1.6 – 5.0

Bobbin Size: Φ 500

Material	Aluminium / Alloy
6B	335
12B	310
18B	275
24B	240
32B	210
Wire Diameter	Φ 1.6 – 5.0

Material	Copper
6B	240
12B	210
18B	180
24B	155
32B	135
Wire Diameter	Φ 1.6 – 5.0

Bobbin Size: Φ 630

Material	Aluminium / Alloy
6B	290
12B	250
18B	210
24B	190
32B	170
Wire Diameter	Φ 1.6 – 5.0

Material	Copper
6B	190
12B	170
18B	150
24B	130
32B	115
Wire Diameter	Φ 1.6 – 5.0
